The Fiber Patchcord SC/UPC SM Duplex Dual Core Optical Cable 5m is a high-quality fiber optic cable designed for reliable data transmission in networking and telecommunications applications. Here are the key details:
Specifications:
- Connector Type: SC/UPC (Square push-pull connector with Ultra Physical Contact polish)
- Fiber Type: Single-Mode (SM) (OS1/OS2 standard, low attenuation for long-distance transmission)
- Cable Type: Duplex (Dual Core) – Two fibers (Tx & Rx) in a single cable
- Length: 5 meters
- Jacket Material: Typically LSZH (Low Smoke Zero Halogen) or PVC
- Diameter: ~2.0mm or 3.0mm (slim or standard thickness)
- Wavelength: 1310nm/1550nm (standard for single-mode)
- Attenuation: ≤0.4 dB/km (typical for single-mode)
- Durability: Bend-insensitive fiber (BIFF) options available
Common Uses:
✔ Telecommunications (FTTH, GPON, FTTx)
✔ Data Centers (server-to-switch connections)
✔ Enterprise Networks (LAN/WAN backbone)
✔ CATV & CCTV systems
✔ Test & Measurement Equipment
Advantages:
✅ Low signal loss (UPC polish ensures better return loss)
✅ Secure connection (SC connectors snap into place firmly)
✅ Single-mode efficiency (long-distance, high-speed data transfer)
✅ Duplex design (simplifies bidirectional communication)
